Behringer Flow 4VIO

The FLOW 4VIO expander brings added muscle to the FLOW 4V by acting as an external stagebox with four additional dual‑stage microphone preamps and two dedicated headphone amps. It’s built with the same true 32‑bit architecture as the main unit, so when you double your available inputs, you also double them without compromising the sound. The extra preamps deliver the same huge dynamic range of up to 142 dB, giving productions more room to grow while keeping audio effortlessly clean and unclipped.

For monitoring, FLOW 4VIO broadens what’s possible on set. With two more headphone amplifiers on board, the system offers three fully independent headphone feeds, each capable of driving high‑impedance studio cans or handling sensitive in‑ear monitors without distortion. It removes the need for splitters or workarounds and makes it easier for multiple team members to monitor exactly what they need during filming.

All of this connects through a single StageConnect cable, which carries audio, clock, control data, and even power. The expander can live right beside the camera or sit up to 40 meters away using standard DMX cabling, keeping setups clean and flexible. StageConnect’s sub‑millisecond latency and uncompressed signal path mean the additional I/O behaves like a natural extension of the FLOW 4V, and the system can even integrate with other StageConnect‑enabled devices, including mixers like WING.

By pairing FLOW 4V with FLOW 4VIO, you expand to eight inputs without adding complexity or changing how you work. The result is a compact, scalable setup that fits naturally into modern video workflows, offering more room for microphones, better monitoring options, and seamless on‑set performance.

FEATURES

• I/O Extension for FLOW 4V mixers, providing 4 additional microphone preamps with dual-stage A/D converters for ultimate dynamic range

• 2 headphone outputs with separate level controls

• Class-compliant USB Audio/ MIDI interface

• StageCONNECT multi-channel audio transmission at sub-millisecond latency, 24 Bit uncompressed PCM, 44.1/48 kHz, using standard XLR cable - for connecting the FLOW 4VIO or other I/O devices

• Able to power a connected FLOW 4V field recorder and mixer remotely via single XLR cable

• Can also be used as a class-compliant 4 x 4 channel USB audio interface

• Remote power available from a Behringer WING StageConnect port and connect as a 4 x 4 channel I/O extension

• Powered via USB-C, power adaptor included, or via XLR StageConnect from compatible devices

• 1/4-20 integrated thread and screw attaches to camera and tripods, with integrated allen-wrench

SPECIFICATIONS

General Specs
Frequency Range (± 1 dB): 5 Hz - 22 kHz
Dynamic Range (Inputs): 140 dB (142 dB A-weighted)

Mic Inputs
Type: 4 × XLR / 1/4" TRS combo jacks, balanced
EIN (20 Hz to 20 kHz):  -130dBu (-132dBu A-weighted)
Distortion (THD + N): 0.007% @ -40 dBu in, 0.003% @ -20 dBu in
Crosstalk rejection @ 1 kHz, adjacent channels: -110 dB
Max Input Level: XLR: +18 dBu
Impedance: XLR: 9.5 kΩ bal
Max Gain: +70 dB
Phantom Power: + 48 V, switchable

Phones Outputs
Type: 2 x 1/4" TRS jack, stereo
Max Output level (30 Ω load): 72 mW
Distortion (THD+N, 30 Ω load): 0.005%

USB Audio Interface
Type: USB 2.0
Connector: Type C
Sample Rate: 48 kHz
Bit Depth: 24-bit / 32-bit float
Channels at Host: 4 IN / 4 OUT

Power Supply / Voltage:
Connector: USB-C
Power Supply / Voltage: USB-C PD
Power Consumption: 8 W

Dimensions / Weight
Dimensions (H x W x D): 53mm x 184mm x 128mm
Weight: 750g
